Proposed Library Building for the University of Adelaide - sheet no. 7

Alternate IDhttp://hdl.handle.net/2440/111246 Last edited by: Samantha Farnsworth

DateJanuary 1930 Last edited by: Samantha Farnsworth

FormatBuilding planDescription

Plan for the proposed Barr Smith Library prepared by Woods, Bagot, Jory and Laybourne-Smith architects. Shows half plan of portico, half elevation of portico, section through entrance, section through pediment, exterior.

Scale: Two feet per one inch.

CreatorWoods, Bagot, Jory and Laybourne-SmithKeywordsBarr Smith Library plansarchitectural plansLanguageEnglish

Proposed Library Building for the University of Adelaide - sheet no. 7
